Product Feature:
P/N: FL1808-CV24/12120-8W27 /FL1808-CV24/12120-8R/Y/B/G/O
Brand: Epistar or branded chip
Brand: Epistar or branded chip
Chip Wire: 99.99% purity(dia 1.0mm or above) gold wire
Beam Angle: 120° Emitting
Lifetime: LM80- 50000Hrs
Operating Temp. -20 ~ 45°C
PCB: 2Oz Cooper/ double-side FPCB
Mounting: Imported 3M tape 300sle
BIN: ONE BIN Only
Luminaire in: CLASS II/III
Packing: 300meter/Ctn. (68x26x28cm)
.jpg)
Product Specification:
.jpg)
.jpg)
.jpg)
Product Specification:
| LED/M | Power | Voltage | Width | Lumen | CRI | Cut length | Color | Length (two side Feed) |
|
| 120 | 9.6W/m | 12/24V | 8mm | 910-960lm | 95 | 3led/25mm 6led/60mm |
2700k, 3000k, 4000k, 6500k | 5m/pcs | 16.40ft/pcs |
| 120 | 9.6W/m | 12/24V | 8mm | / | / | 3led/25mm 6led/60mm |
Red /Yellow /Blue/ Green/ Orange | 5m/pcs | 16.4ft/pcs |
| Tips: other customized color or to build your customized Bin code system pls contact us further. |
Note:
1. free sample and quick delivery within 3working days
2. Pls contact us for detail data sheet / High Quality Picture
3. Customized led strip light is accepted.
4. IES Document / Test Report available.
5. Pls contact us for DWG/CAD drawing
